GLMC01
Asialeren
8517710000
| Quantity: | |
|---|---|
| PDF Export | |
Technical Specifications | |
Part Number | GLMC01 |
Frequency Range | 18-40GHz |
VSWR（typical） | 2.5:1 |
Gain（typical） | >2dBiC |
3dB beam width（Azimuth/Elevation） | 60 °-80 ° |
Axial ratio | 1-3 dB Typ |
Polarization | Right Hand Circular |
Beam squint | ＜5 ° |
Front to back ratio | >25dB |
Amplitude matching | ＜0.2dB |
Connector Type | SMA（F） |
Power Rating | 5W |
Radome Type | For Sea applications |
Environmental screening | MIL-STD-810H |
Operating temperature range | -55 to 85 ° |
Quantity | 08 |
Multiband operation : Spiral antennas can operate at multiple frequencies and are suitable for communication systems that need to cover multiple frequency bands.
High gain : Through optimal design, spiral antenna can achieve higher gain and improve signal transmission efficiency.
Directionality : Some types of spiral antennas have better directionality and are suitable for signal transmission in specific directions.
