Lora Antenna | |
GL868915 | |
Electrical Index | |
Frequency-MHz | 868-915 |
VSWR | ＜1.5 |
Gain-dBi | 3 |
Normal Impedance-Ω | 50 |
Polarization | Liner |
Mechanical Index | |
Cable Length | RG178，100mm |
Connector | SMA male |
Antenna Dimension-mm | 20*73 |
Material | ABS |
Installation Way | Screw |
Vibration | 10 to 55Hz with 1.5mm amplitude 2hours |
Environmentally Friendly | ROHS Compliant |
Temperature-℃ | -40～＋85 |
Humidity-﹪ | 5～95 |
Product Introduction
Targeted Frequency Band：Operating in the 868 - 915MHz frequency range, the GL868915 is specifically designed for LoRa applications. This frequency band is widely used in LoRaWAN networks, ensuring seamless integration with LoRa - enabled devices and gateways. It allows for efficient communication within the LoRa ecosystem, enabling long - range and low - power data transmission.
Good Signal Gain：With a gain of 3 dBi, the antenna effectively boosts the LoRa signal strength. This gain helps in extending the communication range of LoRa devices. In areas with weak signals or long - distance communication requirements, the 3 dBi gain can significantly improve the signal quality, reducing the likelihood of data loss and ensuring reliable communication.
Low VSWR and Standard Impedance：Featuring a VSWR of less than 1.5 and a normal impedance of 50Ω, the GL868915 ensures efficient power transfer. A low VSWR minimizes signal reflection, which means more of the transmitted power is used for signal radiation. The 50 - ohm impedance is a standard in the industry, making it easy to connect the antenna to other components in a LoRa system, such as LoRa modules and gateways.
Convenient Installation：The GL868915 comes with an SMA male connector and has a screw - type installation method. The SMA male connector provides a secure and reliable connection to compatible devices. The screw - type installation allows for easy and stable mounting on various surfaces, whether it's on a building wall, a pole, or an equipment enclosure. This makes it suitable for both indoor and outdoor installations.
Durable and Environmentally Friendly：Made of ABS material, the antenna is durable and can withstand various environmental conditions. ABS is known for its strength and resistance to impact. Additionally, the antenna is ROHS compliant, which means it is environmentally friendly. It can operate within a wide temperature range of - 40°C to + 85°C and a humidity range of 5% - 95%, making it suitable for use in different climates and environments.
Application scenarios
IoT Sensor Networks: Connects sensors in smart cities, agriculture, or energy grids.
Industrial Automation: Ensures stable communication in factories and warehouses.
Remote Monitoring: Ideal for weather stations, asset tracking, and telemetry systems.
Smart Metering: Supports data transmission for utility meters in harsh outdoor conditions.
FAQ
Q:Is this antenna compatible with LoRaWAN devices?
A:Yes, it supports 868-915MHz frequencies, aligning with LoRaWAN standards.
Q:Can it withstand outdoor environments?
A:Absolutely. Its ABS housing and IP-rated design ensure durability against moisture, dust, and temperature extremes.
Q:What cable length is included?
A:A 100mm RG178 cable is pre-attached for flexible routing.
Q:Does it require a ground plane?
A:No, this antenna operates efficiently without a ground plane.
Q:Is the SMA connector reversible?
A:No, the SMA male connector is fixed to maintain signal integrity.
Q:Is it RoHS certified?
A:Yes, it meets RoHS environmental compliance standards.
