4G magnet antenna FME female with 2.5m RG174 cable GL-DYG850

4G Magnet Antenna
GL-DYG850
Electrical Index
Frequency-MHz	700-2700
VSWR	＜2.0
Gain -dBi	5
Normal Impedance -Ω	50
Polarization	Liner
Mechanical Index
Cable Length	RG174,2.5m
Connector	FME  female
Antenna Dimension-mm	Φ50*284
Installation Way	Magnet
Vibration	10 to 55Hz with 1.5mm amplitude 2hours
Environmentally Friendly	ROHS Compliant
Temperature-℃	-40～＋85
Humidity-﹪	5～95

The suction cup antenna is an antenna device used to enhance signal reception and transmission. It is adsorbed on a smooth surface to provide stable support and fixation to ensure that the antenna maintains a good position and direction during use. Suction cup antennas are often used in vehicle-mounted equipment, mobile communication equipment, and other occasions that require mobility and flexibility. Its design makes it easy to install and adjust while maintaining good signal reception performance. The role of the suction cup antenna is to provide a reliable signal connection to help the device achieve better communication effects, thereby meeting the user's demand for high-quality communication.
