The GLONASS Antenna Series is designed for GLONASS receiving antenna applications.The GPS receiving antenna has good stability and sensitivity through the use of high performance proprietary ceramic materials and process and housing.
GL0081
Asialeren
8517710000
| Quantity: | |
|---|---|
| PDF Export | |
1.Antenna specification
GLONASS Antenna | |
GL0081 | |
Electrical Index | |
Center Frequency-MHz | 1610±1 .023MHz |
Gain elevation angle of 100 | -5dBic type (ground plane 30 *30MM) |
Peak gain | -2dbic tye (ground plane30 * 30MM) |
Bandwidth | 10MHZ min （10dB return loss ） |
Polarization | R.H.C. H |
Axia l ratio | 3.0 dB typ( ground plane29*29MM) |
Bandwidth | 10MHZ min （10dB return loss ） |
Mechanical Index | |
Radome material | ABS |
Connector | SMA male |
Antenna Dimension-mm | 46×38 .5× 13 .5mm |
Cable | RG-174 |
Length | 1200±30mm |
Temperature | -40 ° C -- -- +85 ° C |
Humidity | 10 to 95% RH |
2.Outline Drawing
3.Directional diagram
4.Return Loss &VSWR
5.Product Introduction
●Exceptional Stability and Consistency:Enjoy reliable performance with high stability and exceptional consistency, ensuring accurate positioning in various environments.
●Compact Design: Our GLONASS antenna is engineered in a compact size, making it easy to install in tight spaces without compromising functionality.
●Eco-Friendly Compliance:This product is RoHS compliant, reflecting our commitment to environmental standards and safety.
●Versatile Applications: Perfect for a range of applications, including car navigation and logistics positioning, making it an ideal choice for various industries.
●Robust Operating Conditions:Designed to withstand extreme conditions, our antenna functions flawlessly in temperatures ranging from -40 °C to +85 °C and operates effectively in humidity levels of 10% to 95% RH.
FAQ
Q:Can I get one sample?
A:Yes, sample is available.
Q:What's the delivery time?
A:3-5 working days for the sample, 10-15 working days for quantity below 5K.
Q: What are the key features of the GLONASS Antenna GL0081?
A: The GLONASS Antenna GL0081 boasts high stability and consistency, ensuring reliable performance for your applications. Its compact size makes it easy to install in various settings, while compliance with RoHS standards guarantees that it meets environmental safety regulations.
Q: What applications is the GLONASS Antenna GL0081 suitable for?
A: The GLONASS Antenna GL0081 is highly versatile and ideal for various applications, including car navigation systems and logistics positioning. Its reliable performance is crucial for accurate location tracking and navigation in these fields.
Q: What materials are used in the construction of the GLONASS Antenna GL0081?
A:The antenna is constructed with an ABS radome material that provides durability and protection against environmental factors. It is equipped with an RG174 cable, which ensures strong signal transmission, and features an SMA male connector for easy integration with compatible devices.
Q: How does the GLONASS Antenna GL0081 ensure stable performance?
A: The high stability and consistency of the GLONASS Antenna GL0081 stem from its advanced design and quality materials. This results in superior signal reception and reliable performance in various applications, even in less-than-ideal conditions.
Q: Is the GLONASS Antenna GL0081 compatible with all GPS devices?
A: While the GLONASS Antenna GL0081 is designed to work with systems compatible with the GLONASS standard, it's important to check if your GPS device supports GLONASS functionality. Its SMA male connector allows for easy attachment to a wide range of devices, increasing its compatibility in navigation and positioning applications.
Q: Does the GLONASS Antenna GL0081 come with any warranty?
A: Yes, the GLONASS Antenna GL0081 typically comes with a manufacturer's warranty that covers defects in materials and workmanship. Please refer to the product's warranty policy for specific details regarding the duration and terms of coverage.
Q: What installation requirements should I consider for the GLONASS Antenna GL0081?
A:Installing the GLONASS Antenna GL0081 is straightforward due to its compact size and SMA male connector, which fits most standard devices. Ensure you have a suitable mounting surface and that the antenna is positioned in an area free from obstructions to maximize signal quality.
Q: Can the GLONASS Antenna GL0081 be used in outdoor environments?
A: The GLONASS Antenna GL0081, made with durable ABS radome material, is suitable for outdoor use. However, it is advisable to install it in a protected location to enhance its longevity and ensure consistent performance in harsh weather conditions.
