GL8090V-10
Asialeren
8517710000
| Quantity: | |
|---|---|
| PDF Export | |
Electrical Specifications | |
Frequency Range | 806-960MHz |
VSWR | ≤1.5 |
Gain | 10dBi |
Horizontal beam width | 45° |
Vertical beam width | 40° |
Front-to-back ratio | ≥16dB |
Polarization | Vertical |
Input Impedance | 50Ω |
Maximum input power | 50W |
Lightning protection | DC Ground |
Mechanical Specifications | |
Input connector type | N female |
Cable | RG58,82.6cm |
Installation | Pole-holding |
Dimensions | 850mm |
Antenna weight | 0.7kg |
Radiating Element Material | Aluminium |
Operating temperature | -40°C to +70 °C |
Product Introduction
●High Gain Performance: Delivers 10dBi gain for enhanced signal strength and extended coverage.
●Dual Beam Width Optimization: Features a 45° horizontal and 40° vertical beamwidth for balanced directional coverage.
●Robust Build with Aluminum Elements: Lightweight (0.7kg) yet durable radiating elements made of corrosion-resistant aluminum.
●Wide Operating Temperature Range: Functions reliably in extreme conditions from -40°C to +70°C.
●Integrated Lightning Protection: DC grounding ensures safety against electrical surges in outdoor installations.
FAQ
Q: What frequency range does the GL8090V-10 support?
A: The frequency range is 806-960MHz.
Q: Is this antenna suitable for harsh weather conditions?
A: Yes, it operates reliably in temperatures from -40°C to +70°C and includes lightning protection for outdoor durability.
Q: What type of connector does the antenna use?
A: It features an N female connector, compatible with standard coaxial cables.
Q: Can this antenna be mounted on a pole?
A: Yes, it is designed for pole-holding installations, making it ideal for rooftops or towers.
Q: What is the front-to-back ratio of this Yagi antenna?
A: It offers a ≥16dB front-to-back ratio, ensuring minimal interference from rear signals.
