GL-DY8027V9
Asialeren
8517710000
| Quantity: | |
|---|---|
| PDF Export | |
Electrical Specifications | ||
Frequency Range-MHz | 806-960 | 1710-2700 |
VSWR | ≤1.5 | ≤1.5 |
Gain-dBi | 8/9 | |
Horizontal beam width | 90/60° | |
Vertical beam width | 70/55° | |
Front-to-back ratio-dB | ≥15 | |
Polarization | Vertical | |
Input Impedance-Ω | 50 | |
Maximum input power-W | 50 | |
Lightning protection | DC Ground | |
Mechanical Specifications | ||
Input connector type | N-K | |
Installation | Pole-holding | |
Dimensions-mm | 295×210×65 | |
Antenna weight-KGS | 0.9 | |
Radiating Element Material | AI | |
Radome material | ABS | |
Operating temperature | -40°C to +65 °C | |
Mounting hardware-mm | ￠35～￠60 | |
Rated Wind Velocity-m/s | 60 | |
Product Introduction
●Versatile Wireless Communication: This LPDA antenna operates seamlessly across 2G, 3G, WLAN, and LTE networks, providing exceptional broadband coverage for all your connectivity needs.
●Robust Build Quality: Encased in a high-quality radome, this antenna offers superior protection against environmental factors, ensuring long-lasting performance and reliability.
●Efficient Signal Reception: Designed with a focus on effective signal directionality, our LPDA antenna harnesses increased gain to enhance signal strength, making it ideal for applications such as television reception and radio communication.
●Durable and Lightweight: Constructed from ABS material, this antenna weighs only 0.9 kg, combining durability with ease of installation. The pole-holding mount ensures secure placement in various settings.
●Compact Dimensions:With dimensions of 295 × 210 × 65 mm, this antenna is designed for optimal performance without compromising on space, making it suitable for a variety of installations.
●Wide Application Range: The LPDA antenna's broadband characteristics make it perfect for wireless communications, broadcasting, and any application requiring a wide frequency range. Ideal for TV reception, radio enthusiasts, and measurement equipment.
●Engineered for Excellence: Built with AI radiating element material and a thoughtfully designed structure, our antenna ensures multi-frequency resonance, delivering top-notch performance across a wide range of frequencies.
Upgrade your connectivity experience with our high-performance LPDA antenna, expertly designed for both versatility and reliability!
FAQ
Q:Can I get one sample?
A:Yes, sample is available.
Q:What's the delivery time?
A:3-5 working days for the sample, 10-15 working days for quantity below 5K.
Q: What wireless systems is the LPDA Antenna GL-DY8027V9 compatible with?
A:The LPDA Antenna GL-DY8027V9 is designed to support multiple wireless systems, including 2G, 3G, WLAN, and LTE. This makes it an ideal choice for enhancing communication across various network types.
Q: How durable is this antenna?
A:The LPDA Antenna GL-DY8027V9 features robust construction with a sealed radome, providing excellent protection against environmental factors. Its ABS material adds to its durability, ensuring longevity in outdoor installations.
Q: What type of connector does the LPDA Antenna GL-DY8027V9 use?
A: This antenna is equipped with an N female connector, which is widely recognized for its reliability in providing strong connections in various wireless applications.
Q: Can this antenna be easily mounted?
A:Yes, the LPDA Antenna GL-DY8027V9 includes a pole-holding mounting solution, making installation straightforward and secure. It is designed for versatile mounting options to meet your specific requirements.
Q: What are the dimensions and weight of the LPDA Antenna GL-DY8027V9?
A: The antenna measures 295×210×65mm and has a weight of 0.9KGS. This compact size combined with its lightweight design allows for easy handling and installation, without compromising on performance.
Q: What materials are used in the construction of this antenna?
A: The LPDA Antenna GL-DY8027V9 is made with high-quality ABS material for the radome and features advanced AI radiating element material. These materials are selected based on their ability to withstand conditions while delivering optimal signal performance.
Q: Is this antenna suitable for indoor use?
A: While the LPDA Antenna GL-DY8027V9 can be used indoors, it is primarily designed for outdoor applications where protection from environmental factors is essential. Its robust construction makes it ideal for outdoor setups, ensuring maximum performance in various weather conditions.
For the specific parameters and sizes of this product, please click the right email or telephone to consult us.
