Product name：2.4GHz MIMO Omni Antenna
Product model：GL-DY2400VH12
Applications：
2.4GHz/WLAN/WIFI Wireless System
Features:
High Gain, High isolation
Light weight, Small size
Electrical Specifications | |
Frequency Range-MHz | 2400-2500 |
VSWR | ≤1.5 |
Gain-dBi | 12 |
Isolation between ports-dB | ≥25 |
Horizontal beam width | 360° |
Vertical beam width | 8° |
Polarization | H＋V |
Input Impedance-Ω | 50 |
Maximum input power-W | 100 |
Lightning protection | DC Ground |
Mechanical Specifications | |
Input connector type | 2×N Female |
Connector place | Bottom |
Dimensions-mm | Ф75×1150 |
Antenna weight-KGS | 2.5 |
Radome material | PVC |
Radome color | White |
Operating temperature | -40°c～60°c |
Rated Wind Velocity-m/s | 60 |
Mounting hardware | ￠40～￠75 |
Product Introduction
●Enhanced Signal Performance: Experience superior connectivity with our 2.4GHz MIMO Omni Antenna, designed specifically for WLAN and WiFi wireless systems.
●Powerful High Gain: With a remarkable 12dBi gain, this antenna boosts your wireless signal strength, ensuring reliable and fast connections even at greater distances.
●Compact & Lightweight Design: Weighing only 2.5 kg and measuring 75×1150 mm, our antenna is easy to handle and can be seamlessly integrated into your setup without taking up too much space.
●Versatile Connections: Equipped with dual N Female connectors, this antenna is compatible with various devices, making it an ideal choice for any wireless installation.
●User-Friendly Installation: The included adjustable mounting bracket allows for straightforward installation, enabling you to set up your 2.4GHz MIMO Omni WiFi Antenna quickly and effortlessly.
●Built to Last: Crafted from durable PVC material, our antenna is designed to withstand the elements, offering long-lasting performance for your indoor and outdoor connectivity needs.
FAQ
Q:Can I get one sample?
A:Yes, sample is available.
Q:What's the delivery time?
A:3-5 working days for the sample, 10-15 working days for quantity below 5K.
Q: How much gain can I expect from the 2.4GHz MIMO Omni Antenna?
A: You can expect a high gain of 12dBi from the 2.4GHz MIMO Omni Antenna. This high gain enhances signal strength and coverage, allowing for improved performance of your wireless network. It is perfect for environments needing extended reach.
Q: Is the antenna easy to install?
A: Yes! The 2.4GHz MIMO Omni Antenna comes with an adjustable mounting bracket, facilitating a straightforward installation process. Whether you are an experienced technician or a DIY enthusiast, you will find that setting up this antenna is simple and hassle-free.
Q: What type of connectors does the antenna use?
A:This antenna features two N Female connectors, providing compatibility with various equipment and settings. This flexibility ensures that you can integrate the antenna easily into your existing system.
Q: What materials is the 2.4GHz MIMO Omni Antenna made from?
A: The antenna is constructed from durable PVC material, which ensures longevity and resistance to environmental factors. Its robust design is suited for both indoor and outdoor use, making it a reliable choice for your wireless needs.
Q: What are the dimensions and weight of the antenna?
A:The 2.4GHz MIMO Omni Antenna is compact, measuring 75×1150mm and weighing only 2.5kg. Its lightweight design allows for easy mounting and installation, making it an excellent option even in space-constrained environments.
Q: Can this antenna be used for my home Wi-Fi network?
A:Absolutely! The 2.4GHz MIMO Omni Antenna is perfect for enhancing your home Wi-Fi network. With its high gain and efficient performance, it can significantly improve your wireless coverage and provide a more stable internet connection throughout your space.
Q: Is the 2.4GHz MIMO Omni Antenna suitable for outdoor use?
A:Yes, the durable PVC material makes the 2.4GHz MIMO Omni Antenna suitable for outdoor use. It can withstand various weather conditions, ensuring reliable performance for your wireless network even in challenging environments.
For the specific parameters and sizes of this product, please click the right email or telephone to consult us.
