Terminal Data Transmission Wholesale Supplier 5G Patch Antenna GL-DY017

Patch antennas, also known as microstrip antennas, are a popular choice for wireless communication applications due to their compact size, low profile, and ease of integration. Here are some key features of patch antennas:

1. Compact Size: Patch antennas are known for their small size, making them suitable for applications where space is limited. Their compact form factor allows for easy integration into various devices and systems.

2. Low Profile: Patch antennas have a low profile, which means they are thin and do not protrude significantly from the surface they are mounted on. This makes them aesthetically pleasing and minimizes the risk of damage or interference.

3. Broadband Operation: Patch antennas can be designed to operate over a wide frequency range, making them versatile for different wireless communication standards and protocols. They can support multiple frequency bands or be tuned to specific frequencies.

4. Directional Radiation Pattern: Patch antennas typically have a directional radiation pattern, which means they emit and receive signals in a specific direction. This allows for better signal focusing, increased gain, and reduced interference from other directions.

5. High Gain: Patch antennas can achieve high gain, which refers to the ability to concentrate the signal in a specific direction. High gain antennas provide better signal strength, extended coverage, and improved signal quality.

6. Polarization Diversity: Patch antennas can be designed to support different polarization types, such as linear or circular polarization. This allows for compatibility with various communication systems and helps mitigate signal degradation caused by polarization mismatch.

7. Wide Beamwidth: Patch antennas can have a wide beamwidth, which means they can cover a larger area with their radiation pattern. This is beneficial for applications where a broader coverage area is required.

8. Low Cost: Patch antennas are relatively inexpensive to manufacture compared to other types of antennas. Their simple design and use of printed circuit board (PCB) technology contribute to their cost-effectiveness.

9. Easy Integration: Patch antennas can be easily integrated into PCBs or other surfaces, making them suitable for mass production and high-volume applications. They can be mounted directly on a substrate or embedded within a device.

10. Customizable Design: Patch antennas can be customized to meet specific requirements, such as frequency range, gain, beamwidth, and polarization. This flexibility allows for optimization based on the application's needs.

These features make patch antennas a popular choice in wireless communication systems, including mobile devices, IoT devices, wireless routers, satellite communication, and many other applications where compact size, low profile, and reliable performance are essential.

FAQ

Q1:Can I get one sample?

A1:Yes, sample is available.

Q2:What's the delivery time?

A2:3-5 working days for the sample, 10-15 working days for quantity below 5K.

Q3: What frequency ranges does the 5G patch antenna support?

A3: The 5G patch antenna supports a wide frequency range of 698-960 MHz and 1710-3800 MHz, ensuring compatibility with various 5G networks and other wireless applications. This versatility makes it an excellent choice for enhancing signal quality and coverage.

Q4: What is the gain of the antenna and how does it affect performance?

A4: The antenna provides a gain of 2.5 dBi, which contributes to improved signal strength and reception in both transmitting and receiving conditions. This gain optimizes your device's performance, making it ideal for 5G connections while maintaining a compact form factor.

Q5: What kind of cable is included with the 5G patch antenna and what is its length?

A5: The antenna comes with an RG174 cable, which is known for its excellent signal transmission qualities. The cable length is 2.5 meters, providing flexibility in installation and allowing you to position the antenna optimally for the best performance.

Q6: Can this antenna be easily installed?

A4: Yes, the 5G patch antenna features a 3M sticky installation method, allowing for a quick and hassle-free setup. Simply peel off the backing and adhere the antenna to a suitable surface—no additional tools are required.

Q7: What is the size of the antenna?**

A7:The dimensions of the 5G patch antenna are 115.6 mm in length, 21.7 mm in width, and 5.8 mm in height. Its compact design ensures that it can be easily integrated into various applications without taking up too much space.

Q8: Is the connector type compatible with most devices?

A8: Yes, this antenna features an SMA male connector, which is widely used and compatible with a variety of devices. This makes it suitable for use in mobile communications, IoT applications, and many other systems requiring a reliable 5G connection.

Q9: Will this antenna improve my signal reception?

A9: Absolutely! The 5G patch antenna is designed specifically to enhance signal reception and transmission capabilities, allowing for better communication quality and faster data speeds. Whether you're in a suburban area or urban setting, you can expect a notable improvement in performance.

Feel free to reach out if you have any more questions about our 5G patch antenna!
