GL-DY5158V28
Asialeren
8517710000
| Quantity: | |
|---|---|
| PDF Export | |
Electrical Specifications | |
Frequency Range-MHz | 5150-5850 |
Polarization | Vertical |
VSWR | ≤2.0 |
Gain-dBi | 28 |
Horizontal beam width | 6° |
Vertical beam width | 6° |
Front-to-back ratio-dB | ≥35 |
Input Impedance-Ω | 50 |
Maximum input power-W | 100 |
Lightning protection | DC Ground |
Mechanical Specifications | |
Input connector type | N-K |
Dimensions-m | φ0.6 |
Antenna weight-kg | 5.5 |
Reflector material | Aluminum |
Reflecting surface color | Gray |
Mechanical tilt | 0～20° |
Operating temperature | -40°C to + 65 °C |
Rated Wind Velocity-m/s | 60 |
Mounting hardware -mm | φ50～φ75 |
Product Introduction
●Exceptional Performance: Experience superior connectivity with an impressive 28 dBi gain, ensuring optimal signal strength for your 5GHz WLAN and Wi-Fi wireless systems.
●Versatile Applications: Perfect for both point-to-point and point-to-multipoint communication setups, making it ideal for various networking needs.
●Robust Design: Crafted with high-quality aluminum material, the reflector is designed for durability and longevity, making it resilient to environmental factors.
●Anti-Aging Surface Coating: The antenna features an advanced anti-aging surface coating, providing added protection against wear and degradation over time.
●Compact and Lightweight: With a dimensions of 0.6m and a weight of just 5.5 kg, this antenna is easy to install and manage without compromising performance.
FAQ
Q: What is the primary use of the 0.6m 5GHz parabolic antenna?
A: The 0.6m 5GHz Parabolic Antenna is designed for use in WLAN and WIFI wireless systems, particularly in point-to-point and point-to-multipoint applications. Its high gain of 28 dBi ensures superior signal strength and enhanced connectivity over long distances.
Q: What is the gain and front-to-back ratio of this antenna?
A: The 0.6m Parabolic Antenna boasts an impressive gain of 28 dBi, along with a front-to-back ratio of ≥35 dB. This combination provides excellent directional performance, minimizing interference and enhancing signal clarity for your wireless communications.
Q: What materials are used in the construction of this antenna?
A: This antenna features an aluminum material reflector, ensuring durability and resistance to environmental factors. It also comes with an anti-aging surface coating, enhancing its longevity and performance in various outdoor conditions.
Q: What are the dimensions and weight of the antenna?
A: The 0.6m Parabolic Antenna has a diameter of 0.6 meters and weighs 5.5 kg. This compact size, paired with its lightweight construction, makes it manageable for installation while still providing high-performance capabilities.
Q: What type of connector does this antenna use?**
A: The antenna is equipped with an N-K input connector type, which ensures a reliable and secure connection to your wireless systems, facilitating an efficient signal transmission.
Q: Is the antenna suitable for external use?
A: Yes, the 0.6m 5GHz Parabolic Antenna is specifically engineered for outdoor use, thanks to its anti-aging surface coating and durable aluminum construction. It is built to withstand the elements, maintaining performance reliability over time.
Q: Can I use this antenna with any router or wireless system?
A: The 0.6m Parabolic Antenna can be used with most 5GHz capable routers and wireless systems that support the N-K connector type. Ensure compatibility with your specific equipment for optimal performance.
Q: What kind of performance improvement can I expect with this antenna?
A:By using the 0.6m 5GHz Parabolic Antenna, you can expect significant performance improvements, including enhanced signal strength, greater range, and reduced interference. Its high gain and directional focus help to improve connectivity in challenging environments.
