GL-DYS450AM12PM
Asialeren
8517710000
| Quantity: | |
|---|---|
| PDF Export | |
Item No | GL-DYS450AM12PM | |
Panel(Sector Divided) | 12 | |
Aperture Diameter | 450CM | |
C-Band Gain@ 4GHz | 44.5dB | |
Ku-Band Gain@12.5GHz | ||
F/D Ratio | 0.3 | |
Focus Length | 173.2CM | |
Material | Aluminium Mesh | |
Finish | Polyester Powder Coating | |
Mounting Type | Pole/Polar Mount | |
Elevation Alignment | 0～90° | |
Azimuth Alignment | 0～360° | |
Operational Winds | Able to receive | 25m/sec |
Able to re-set | 40m/sec | |
Not broken & fly away | 60m/sec | |
Ambient Temperature | -40℃～+60℃ | |
Relative Humidity | 0～100% | |
Product Introduction
High - Performance C - Band Reception：The GL - DYS450AM12PM offers an impressive 44.5dB gain in the C - Band at 4GHz. This high gain enables it to effectively capture and amplify weak C - Band signals. Whether for satellite communication, broadcasting, or other C - Band - based applications, it ensures a stable and strong signal connection, providing reliable performance.
Durable and Lightweight Build：Constructed from aluminium mesh with a polyester powder coating, the antenna is both lightweight and highly durable. Aluminium mesh provides good corrosion resistance, and the polyester powder coating protects it from the elements. It can withstand strong winds up to 60m/sec, extreme temperatures from - 40 ℃ to +60 ℃, and high humidity levels of 0 - 100%, ensuring long - term use without significant degradation.
Flexible Mounting Design：Featuring a pole/polar mount design with adjustable elevation (0 - 90°) and azimuth (0 - 360°) alignment, the GL - DYS450AM12PM provides great flexibility in installation. Users can easily optimize the antenna's position to achieve the best signal reception, whether it's for covering a specific area or aligning with a particular satellite.
Optimal F/D Ratio and Focal Length：With an F/D ratio of 0.3 and a focus length of 173.2CM, the antenna is designed to focus signals precisely. This optimal combination enhances the antenna's signal - gathering ability, improving its overall performance and maximizing the utilization of satellite signals.
Wide Environmental Adaptability：Operating within a wide temperature range and high humidity levels, the GL - DYS450AM12PM can function in diverse environments. Its ability to withstand different weather conditions makes it suitable for use in various regions, from cold and harsh terrains to hot and humid climates.
Application scenarios
Satellite TV/radio broadcasting in isolated regions.
Secure military or government communication networks.
Offshore maritime communication for ships or oil rigs.
Disaster recovery and emergency response systems.
FAQ
Q:Does this antenna support Ku-band reception?
A:Ku-band specifications are not listed; contact us for custom configurations.
Q:What pole size is required for installation?
A:Compatible with 3-6 inch diameter poles; mounting hardware is included.
Q:Is professional installation necessary?
A:No—12-panel modular design allows straightforward on-site assembly.
Q:How to maintain the aluminum mesh?
A:Rinse periodically with water; the polyester coating resists rust and debris.
Q:What is the advantage of the aluminium mesh material?
A:The aluminium mesh material is lightweight, which makes the antenna easier to install and transport. It also offers good corrosion resistance, ensuring the antenna's durability in different weather conditions. This helps to extend the lifespan of the antenna, reducing the need for frequent replacements.
