4G Vehicle GPS Tracker CA003-4G 4 Wires CA004-4G 8wires

4G Vehicle GPS Tracker

1. Product functions & parameters

1.1. Product functions: Location query, historical route playback, geo-fence, inflection point supplementary transmission, blind zone supplementary transmission, parking report, voltage detection, overspeed alarm, displacement alarm, power failure alarm (optional), SOS emergency (optional), remote voice record(optional), voice broadcast (optional), temperature detection (optional), remote oil and electricity cut off (optional), remote photographing (optional), fuel level detection (optional), etc. (Note: Different models with different functions, please refer to corresponding models.)

1.2 Product parameters

●Network standard: 4G, 3G, 2G (optional)

●Wide voltage input range: 9-50V/9-75V/9-95V (optional);

●Positioning time: average hot start: ≤3sec(open sky) average cold start: ≤35sec(open sky)

●Positioning accuracy: ≤10m (open sky)

●Working temperature: -20℃-75℃ Important tips: Please install and use correctly within the tolerance range of the equipment performance, if any illegal installation exceeds the equipment performance tolerance range, all the consequences caused by the user shall be borne by themselves!

2. Product accessories and LED status

2.1 Accessories: Standard: GPS tracker/harness/user manual/double-sides sticker Optional: microphone, SOS button, relay, temperature sensor, camera.

2.2 LED status of GPS tracker

2.2.1 Red LED (power supply/working status)

3. GPS tracker installation instructions:

3.1 Preparation before installation：

① Open the packing box and check model, accessories are correct or not, otherwise please contact your dealer.

② SIM card selection, the terminal needs to insert a standard SIM card.

③ For the installation of the SIM card, confirm the orientation of the SIM card according to the type of the SIM card slot of the device, and place the SIM card correctly Note:

⑴ Before installing or removing the SIM card, please switch off the power.

⑵ Please active the GPRS function of the SIM card.

⑶ Please active the caller ID display function of the sim card for remote monitoring (select to enable or not according to the function required by the customer).

⑷ If your SIM card has been turned on and asked to enter the SIM PIN, please refer to your mobile phone user manual to turn off the SIM PIN input function.

⑷ Please make sure that the SIM card has charges

3.2 installation The GPS device should be installed at hidden positions. We highly suggest that installed by professional technicians. Please note below items:

2 Installation position should be as concealed as possible, and be waterproof.

② Keep away from emission sources, such as reversing radar, anti-theft device and other vehicle-mounted communication equipment.

③ The device finished with built-in GSM antenna and GPS antenna. When installing, make sure that the front is facing upward (toward the sky), and there is no metal object upside. The recommended installation position as below:

⑴The hidden place in the decorative panel under the front windshield of the car.

⑵ Hidden places around the front dashboard of the car (the skin is made of non-metallic material).

(3) Under the decorative panel under the rear windshield of the car.

⑷Inside the car door or the center pillar.

⑸ In the dashboard of the electric vehicle/motorcycle or the hidden place under the rear seat
