GL-DY3500V8
Asialeren
8517710000
| Quantity: | |
|---|---|
| PDF Export | |
Electrical Specifications | |
Frequency Range- MHz | 3400-3600 |
VSWR | ≤1.5 |
Gain- dBi | 8 |
Horizontal beam width | 360° |
Vertical beam width | 15° |
Polarization | Vertical |
Input Impedance-Ω | 50 |
Maximum input power- W | 50 |
Lightning protection | DC Ground |
Mechanical Specifications | |
Input connector type | N-K |
Connector place | Bottom |
Dimensions- mm | Ф20×430 |
Antenna weight- kg | 0.7 |
Radome material | Fiberglass |
Radome color | gray |
Operating temperature | -40°c～60°c |
Rated Wind Velocity- m/s | 60 |
Mounting hardware- mm | ￠35～￠60 |
Product Introduction
5G - ready Frequency Range: Operating in the 3400 - 3600MHz frequency band, it is well - suited for 5G new network systems and point - to - multipoint applications, enabling high - speed data communication.
Good Gain Performance: Offering a gain of 8 dBi, it provides sufficient signal enhancement for reliable 5G signal transmission and reception over a reasonable distance.
All - round Coverage: The 360° horizontal beamwidth ensures omni - directional signal coverage, making it convenient for scenarios where signals need to reach multiple devices in different directions.
Robust Construction: Made of high - quality fiberglass radome, it can endure harsh weather conditions. It has an operating temperature range from - 40°C to 60°C and can withstand a rated wind velocity of 60 m/s.
Easy Integration: With an N - K connector at the bottom, it can be easily connected to various 5G devices and systems. The provided mounting hardware for poles with a diameter of 35 - 60 mm simplifies the installation process.
5G Base Stations: Ideal for deployment in 5G base stations in urban areas to provide wide - area coverage and support high - density device connections for applications like smart cities, IoT, and high - speed mobile broadband.
Industrial 5G Networks: In industrial settings such as factories and warehouses, it can be used to establish 5G - based wireless networks for machine - to - machine communication, automated production lines, and real - time monitoring systems.
Outdoor 5G Hotspots: For creating outdoor 5G hotspots in stadiums, concert venues, or large public areas, enabling users to experience high - speed 5G connectivity during events.
5G - enabled Transportation: In the transportation industry, it can be installed on vehicles, roadsides, or railway stations to support 5G - based communication for autonomous driving, vehicle - to - everything (V2X) communication, and real - time passenger information systems.
5G - powered Smart Buildings: For integrating 5G networks into smart buildings, providing high - speed wireless connectivity for office spaces, residential complexes, and commercial centers, supporting various smart applications and services.
Q:What is the maximum input power for the GL - DY3500V8 antenna?
A:The maximum input power is 50W.
Q:Can it work with existing 4G devices?
A:It is primarily designed for 5G networks operating in the 3400 - 3600MHz frequency range. While some 4G devices may be compatible, it's best used with 5G - specific equipment for optimal performance.
Q:How does the vertical beamwidth of 15° affect the signal?
A:The 15° vertical beamwidth helps to focus the signal in a specific vertical area, which can be beneficial for adjusting the signal distribution based on the installation height and the target area of coverage.
Q:Is the antenna waterproof?
A:The fiberglass radome construction provides good protection against water and other weather elements, making it suitable for outdoor use in various weather conditions.
Q:Can it be used in a high - interference environment?
A:The antenna's design and performance can help mitigate some interference. However, in extremely high - interference environments, additional measures such as proper frequency planning and interference suppression techniques may be required.
Q:How long is the warranty period?
A:The warranty period may vary. Please contact our sales team or refer to the product documentation for specific warranty information.
Q:Can I use an extension cable with the antenna?
A:Yes, you can use an appropriate extension cable if the original cable length is not sufficient for your installation requirements. Make sure to choose a cable with suitable impedance and signal - transmission characteristics.
