Patch Antenna | |
GL026 | |
Electrical Index | |
Frequency-MHz | 2400-2500/5150-5850 |
VSWR | ＜2.0 |
Normal Impedance-Ω | 50 |
Gain-dBi | 3 |
Polarization | vertical |
Lightning Protection | DC Ground |
Mechanical Index | |
Cable Length | customize |
Wire Specification | RG1.13 |
Antenna Dimension-mm | 51.3*9.2 |
I put connector type | IPEX-1 or Requested |
Antenna weight(kg) | 0.01 |
Openrating temperature(℃) | -40～85 |
Product Introduction
●Dual-Band Coverage (2400-2500/5150-5850MHz)
Supports both 2.4GHz and 5GHz frequencies, ideal for WiFi, Bluetooth, and IoT applications.
●Low VSWR (<2.0) & Stable Performance
Ensures minimal signal loss and reliable connectivity for high-speed data transmission.
●Ultra-Compact Design (51.3*9.2mm) & Lightweight (0.01kg)
Perfect for space-sensitive installations in drones, wearable devices, and compact electronics.
●Wide Operating Temperature Range (-40°C to +85°C)
Maintains performance in extreme environments, from freezing winters to industrial heat.
●DC Ground Lightning Protection & Customizable Options
Protects against surges; choose cable length (RG1.13) and connectors (IPEX-1 or custom).
IoT Devices: Reliable connectivity for smart sensors and agricultural monitoring systems.
WiFi Routers/Modules: Enhances signal stability for home and industrial networks.
Drones & Robotics: Lightweight design suits aerial and mobile applications.
Outdoor Telecom Equipment: Withstands temperature extremes and environmental stress.
Smart Home Systems: Compact size integrates seamlessly with hubs and security devices.
Q: Can I request a specific cable length?
A: Yes, the cable length and connector type (e.g., IPEX-1) are fully customizable.
Q: Is this antenna waterproof?
A: While not fully waterproof, its rugged design performs well in humid conditions (5-95% humidity).
Q: Does it support 5G networks?
A: No, it’s optimized for 2.4GHz/5GHz WiFi and IoT bands. For 5G, check our other models.
Q: What industries is this antenna best for?
A: IoT, telecom, smart home, robotics, and industrial automation.
Q: Is it certified for safety standards?
A: Yes, ROHS-compliant and DC ground lightning protection ensures safety.
Q: What’s the lead time for custom orders?
A: Typically 7-10 business days; contact sales for exact details.
