High Accuracy GNSS Active Antenna GL236
The High Accuracy GNSS Active Antenna GL236 is a two-pin antenna with a frequency range of 1561.098~1602MHz. It has a right-hand circular polarization (RHCP) and a gain of 5dBic at the zenith. The V.S.W.R is less than 1.5, and the impedance is 50 Ω. The antenna has dimensions of 33.533.56mm and an axial ratio of 3dB (maximum). The LNA gain is 28±2dB, and the noise figure is less than or equal to 1.5dB. It operates on a supply voltage of 3~5V DC with a current consumption of less than 20mA. The mechanical specifications include an RG174 cable and an SMA or other connector. The radome material is ABS, and it can be mounted using a magnet or adhesive. The antenna is environmentally friendly and ROHS compliant, with an operating temperature range of -40℃~+85℃ and a relative humidity of up to 95%. It has an ingress protection rating of IP67 and can withstand vibrations of 10 to 55Hz with a 1.5mm amplitude for 2 hours.
Item | Specifications | |
Antenna(2 pins) | Frequency Range | 1561.098~ 1602MHz |
Polarization | RHCP | |
Gain | 5dBic@PCB（Zenith） | |
V.S.W.R | ＜1.5 | |
Impedance | 50 Ω | |
Dimension | 33.5*33.5*6mm | |
Axial Ratio | 3dB（max） | |
LNA | Gain | 28±2dB |
Noise Figure | ≤1.5dB | |
Supply Voltage | 3~5V DC | |
Current Consumption | ＜20mA | |
V.S.W.R | ＜2.0 | |
Mechanical | Cable | RG174 |
Connector | SMA or others | |
Radome Material | ABS | |
Mounting Method | Magnet/Adhesive | |
Environmental | Operating Temperature | -40℃~+85℃ |
Relative Humidity | Up to 95% | |
Ingress Protection | IP67 | |
Vibration | 10 to 55Hz with 1.5mm amplitude 2hours | |
Environmentally Friendly | ROHS Compliant | |
High Accuracy GNSS Active Antenna GL236
The High Accuracy GNSS Active Antenna GL236 is a two-pin antenna with a frequency range of 1561.098~1602MHz. It has a right-hand circular polarization (RHCP) and a gain of 5dBic at the zenith. The V.S.W.R is less than 1.5, and the impedance is 50 Ω. The antenna has dimensions of 33.533.56mm and an axial ratio of 3dB (maximum). The LNA gain is 28±2dB, and the noise figure is less than or equal to 1.5dB. It operates on a supply voltage of 3~5V DC with a current consumption of less than 20mA. The mechanical specifications include an RG174 cable and an SMA or other connector. The radome material is ABS, and it can be mounted using a magnet or adhesive. The antenna is environmentally friendly and ROHS compliant, with an operating temperature range of -40℃~+85℃ and a relative humidity of up to 95%. It has an ingress protection rating of IP67 and can withstand vibrations of 10 to 55Hz with a 1.5mm amplitude for 2 hours.
Item | Specifications | |
Antenna(2 pins) | Frequency Range | 1561.098~ 1602MHz |
Polarization | RHCP | |
Gain | 5dBic@PCB（Zenith） | |
V.S.W.R | ＜1.5 | |
Impedance | 50 Ω | |
Dimension | 33.5*33.5*6mm | |
Axial Ratio | 3dB（max） | |
LNA | Gain | 28±2dB |
Noise Figure | ≤1.5dB | |
Supply Voltage | 3~5V DC | |
Current Consumption | ＜20mA | |
V.S.W.R | ＜2.0 | |
Mechanical | Cable | RG174 |
Connector | SMA or others | |
Radome Material | ABS | |
Mounting Method | Magnet/Adhesive | |
Environmental | Operating Temperature | -40℃~+85℃ |
Relative Humidity | Up to 95% | |
Ingress Protection | IP67 | |
Vibration | 10 to 55Hz with 1.5mm amplitude 2hours | |
Environmentally Friendly | ROHS Compliant | |
