GL-DY2458V2810
Asialeren
8517710000
| Quantity: | |
|---|---|
| PDF Export | |
Electrical Specifications | |
Frequency Range | 2400-2500/5150-5850MHz |
VSWR | ≤1.8 |
Gain-dBi | 8/10 |
Isolation between ports-dB | ≥25 |
Horizontal beam width | 360° |
Verticalbeam width | 18°/ 11° |
Polarization | V |
Input Impedance-Ω | 50 |
Maximum input power-W | 100 |
Lightning protection | DC Ground |
Mechanical Specifications | |
Input connector type | 2×N-K |
Connector place | Bottom |
Dimensions-mm | Ф75×465 |
Antenna weight-KGS | 1.3 |
Radome material | PVC |
Radome color | White |
Operating temperature | -40°c～60°c |
Rated Wind Velocity-m/s | 60 |
Mounting hardware-mm | ￠40～￠75 |
Product Introduction
Wide Frequency Compatibility：Operating in the 2400 - 2500MHz and 5150 - 5850MHz frequency ranges, it is suitable for both 2.4G and 5G WLAN/WIFI systems. This makes it compatible with a vast array of wireless devices, from older 2.4G - only gadgets to the latest 5G - enabled smartphones and routers.
High Gain Performance：With a gain of 8 dBi in one frequency band and 10 dBi in the other, it significantly enhances the signal strength. This allows for long - range signal transmission and better penetration through obstacles, ensuring stable connections even in challenging environments.
Excellent Isolation：The isolation between ports is ≥25dB, minimizing interference between different data streams. This feature is crucial for maintaining high - quality communication, especially in multi - user or high - traffic scenarios where multiple devices are connected simultaneously.
Omni - directional Coverage：Featuring a 360° horizontal beamwidth, it provides all - around signal distribution. Devices can connect to the antenna from any direction without the need for precise alignment, making it ideal for areas where a wide coverage area is required.
Lightweight and Compact：Weighing only 1.3KGS and with dimensions of Φ75x465mm, it is easy to handle and install. Its small size also makes it less obtrusive, whether installed indoors or outdoors, and reduces the structural load on mounting surfaces.
Durable and Protected：Made of PVC radome material, it can withstand various environmental conditions, from extreme temperatures ranging from - 40°C to 60°C to strong winds with a rated velocity of 60 m/s. The DC ground lightning protection further safeguards the antenna and connected devices from electrical surges caused by lightning, ensuring long - term reliability.
Large Office Complexes：In large - scale office buildings with multiple floors and a high density of employees using various wireless devices for work, such as laptops, tablets, and smartphones, this antenna can provide stable and high - speed WIFI coverage across the entire complex. It supports seamless communication for video conferencing, cloud - based applications, and large - file transfers.
Shopping Malls and Retail Centers：These areas require extensive WIFI coverage to support customers using mobile devices for shopping, mobile payments, and accessing in - store services. The antenna's omni - directional coverage and high gain ensure that there are no dead zones, and it can handle the large number of concurrent connections.
Hotels and Resorts：Guests expect reliable WIFI in their rooms, lobbies, restaurants, and other common areas. The GL - DY2458VB10 antenna can meet these demands, providing a smooth online experience for activities like streaming, online gaming, and business - related tasks.
Industrial Warehouses：With the increasing use of wireless - enabled devices in industrial settings, such as automated guided vehicles (AGVs), inventory management systems, and remote - controlled machinery, this antenna can establish a stable wireless network. Its high gain and isolation features are essential for maintaining reliable communication in an environment filled with potential interference.
Outdoor Public Spaces：In parks, stadiums, and large event venues, it can be installed on poles or buildings to offer WIFI access to a large number of visitors. Its durable construction and omni - directional coverage make it suitable for outdoor use, even in harsh weather conditions.
Educational Campuses：From classrooms and libraries to student dormitories and outdoor study areas, this antenna can provide consistent WIFI connectivity. It supports students and teachers in accessing educational resources, collaborating online, and conducting research without signal disruptions.
Q:What is the main advantage of the high isolation feature?
A:The high isolation between ports (≥25dB) reduces interference between different data streams. This allows the antenna to handle multiple connections simultaneously without signal degradation, ensuring smooth and reliable communication for all connected devices.
Q:Can the antenna be used with any WIFI router?
A:The antenna is designed for 2.4G and 5G WLAN/WIFI systems. As long as the router operates within the 2400 - 2500MHz or 5150 - 5850MHz frequency ranges and supports MIMO technology, it should be compatible. However, for optimal performance, it's recommended to check the router's specifications.
Q:How do I install the antenna outdoors?
A:It comes with 2xN - K connectors at the bottom. You can mount it on a pole with a diameter of 40 - 75 mm using the appropriate mounting hardware. Make sure to follow the installation instructions carefully and ensure proper grounding for the lightning protection feature.
Q:What is the maximum number of devices the antenna can support?
A:The number of devices the antenna can support depends on various factors, such as the network environment, the data usage patterns of the devices, and the capabilities of the connected router. The MIMO technology and high isolation do enable it to handle a relatively large number of concurrent connections, but an exact number cannot be specified without specific context.
Q:Does the antenna support the latest WIFI standards like 802.11ax (Wi - Fi 6)?
A:Since it covers the relevant 2.4G and 5G frequency bands, it is compatible with devices operating on 802.11ax (Wi - Fi 6) and other WIFI standards within those frequency ranges. However, the actual performance may also depend on the specific capabilities of the connected devices.
Q:How does the vertical beamwidth affect the signal distribution?
A:The antenna has different vertical beamwidths for different frequency bands (18° and 11°). A narrower vertical beamwidth helps to focus the signal more horizontally, which can be beneficial for covering a larger area at a specific height or for reducing interference from above or below the antenna's installation level.
Q:What is the warranty period for the antenna?
A:The warranty period for the GL - DY2458VB10 antenna may vary. Please contact our sales team or refer to the product documentation for detailed warranty information.
