Product: 4G Magnet Antenna SMA R/A male | |
PN: GLG093 | |
Electrical Index | |
Frequency-MHz | 700-2700 |
VSWR | ＜1.5 |
Gain-dBi | 3-5 |
Normal Impedance-Ω | 50 |
Polarization | Liner |
Mechanical Index | |
Cable Length | RG174,2.5m |
Connector | SMA male |
Antenna Dimension-mm | Ø62*213 |
Installation Way | Magnet |
Material | Copper |
Vibration | 10 to 55Hz with 1.5mm amplitude 2hours |
Environmentally Friendly | ROHS Compliant |
Temperature-℃ | -40～＋85 |
Humidity-﹪ | 5～95 |
Gain and Efficiency
2D radiation pattern
3D radiation pattern
Product Advantage
●5dBi Gain: Enhance your signal strength with our 4G full band magnet antenna, offering a robust 5dBi gain for superior performance in various environments.
●Premium Copper Alloy Material: This antenna is made of high-quality copper alloy with excellent conductivity and good corrosion resistance, ensuring stability in a variety of environments and providing long-term reliable connection for your device.
●SMA Male Connector with Magnet Installation: Designed for easy setup, the antenna features an SMA male connector and a magnet installation way, allowing for quick and secure attachment to metal surfaces.
●Extended RG174 Cable: With a generous 2.5m long RG174 cable, this magnet antenna GLG093 offers flexible placement options, enabling you to position it for optimal reception without hassle.
●ROHS Compliant & Environmentally Friendly: Our 4G full band magnet antenna meets ROHS standards, ensuring an environmentally friendly choice while delivering exceptional linear polarization and wide frequency coverage from 700-2700MHz.
FAQ
Q:Can I get one sample?
A:Yes, sample is available.
Q:What's the delivery time?
A:3-5 working days for the sample, 10-15 working days for quantity below 5K.
Q: Is the GLG093 antenna compatible with all 4G networks?
A: Yes, the GLG093 antenna is designed to support full band 4G coverage from 700 to 2700MHz, making it compatible with all major 4G networks. This versatility ensures that you will experience improved signal quality and data transmission regardless of your service provider.
Q: How do I install the GLG093 magnet antenna?
A:Installing the GLG093 magnet antenna is simple and straightforward. With its built-in magnet, you can securely attach it to any metallic surface for optimal signal reception. Connect the antenna to your device using the SMA male connector and position it in an area with minimal obstructions for the best performance. The included 2.5m RG174 cable allows for flexible placement.
Q: What is the advantage of the linear polarization in the GLG093 antenna?
A:Linear polarization helps in minimizing multipath interference, which can significantly enhance signal clarity and reduce dropouts. The GLG093's design ensures that it can effectively receive and transmit signals over large distances, making it an excellent choice for both indoor and outdoor environments.
Q: Is the GLG093 antenna suitable for outdoor use?
A: Yes, the GLG093 antenna is suitable for outdoor use, thanks to its robust construction and high-quality materials. Its copper components are designed to withstand various environmental conditions, ensuring longevity and stable performance. However, we recommend ensuring that the antenna is securely mounted and protected from extreme weather conditions for optimal results.
Q: Does the GLG093 antenna require any additional equipment for optimal use?
A: The GLG093 antenna is designed to be plug-and-play with most devices that have an SMA connector, so it does not require additional equipment for basic functionality. However, if you are using it for specific applications, such as in a high-interference environment, you may consider using it in conjunction with a signal amplifier for enhanced performance.
Q: What maintenance is required for the GLG093 magnet antenna?
A: The GLG093 magnet antenna requires minimal maintenance. Regularly check for any physical damages or wear and clean any dirt or debris from the antenna surface and the magnetic base. This will help maintain optimal performance and prolong the lifespan of the antenna.
For the specific parameters and sizes of this product, please click the right email or telephone to consult us.
