GL-DY7027V3B
Asialeren
8517710000
| Quantity: | |
|---|---|
| PDF Export | |
Electrical Specifications | ||
Frequency Range-MHz | 698-960 | 1710-2700 |
VSWR | ≤1.8 | ≤1.5 |
Gain-dBi | 2.5 | 3.5 |
Horizontal beam width | 360° | 360° |
Verticalbeam width | 65° | 55° |
Polarization | Vertical | |
Input Impedance-Ω | 50 | |
Maximum input power-W | 50 | |
Lightning protection | DC Ground | |
Mechanical Specifications | ||
Input connector type | N-K | |
Dimensions-mm | Ø165×100 | |
Antenna weight-KGS | 0.3 | |
Radiating Element Material | AI | |
Radome material | ABS | |
Radome color | White | |
Operating temperature | -40°C to +65 °C | |
Product Introduction
Compact and Portable Design：The GL-DY7027V3B is lightweight and small in size, which makes it easy to install on ceilings. Its compact design allows for convenient installation in various indoor spaces without adding excessive weight or taking up much space, ensuring a seamless integration into indoor environments.
Wideband Frequency Coverage：Operating across the 698 - 960MHz and 1710 - 2700MHz frequency bands, this antenna offers wideband functionality. It can support multiple wireless communication standards, including 2G, 3G, 4G, and some WLAN technologies. This wide - band compatibility ensures that different wireless devices can connect effectively within the indoor area.
Good Signal Gain：With a gain of 2.5 dBi in the 698 - 960MHz band and 3.5 dBi in the 1710 - 2700MHz band, the GL-DY7027V3B effectively boosts the signal strength. This helps to extend the wireless coverage area, reducing signal dead zones and providing a more stable connection for devices. It is especially useful in large indoor spaces where a strong and consistent signal is required.
Anti-ultraviolet and Durable Radome：Featuring an anti - ultraviolet ABS radome, the antenna is protected from UV damage. This is important for indoor installations where the antenna may be exposed to sunlight filtering through windows. The ABS radome also provides durability, protecting the internal components from dust, moisture, and minor impacts.
Vertical Polarization and 360° Horizontal Beamwidth：The vertical polarization of the GL-DY7027V3B can help reduce interference in indoor wireless communication. Coupled with its 360° horizontal beamwidth, it ensures comprehensive horizontal coverage. This means that wireless devices in any part of the room can receive signals, providing a more reliable and uniform wireless experience.
Office Buildings：In office environments, the GL-DY7027V3B can be installed on the ceilings of open - plan offices or individual rooms. It provides reliable wireless coverage for employees' laptops, smartphones, and other wireless devices, enabling seamless communication and access to the office network.
Retail Stores：Retail stores rely on stable wireless connectivity for point - of - sale systems, inventory management devices, and customer - facing applications. Installing the GL-DY7027V3B on the ceiling ensures that there are no signal dead zones, enhancing the shopping experience for customers and improving operational efficiency for store staff.
Hotels：Hotels need to offer high - quality wireless services to guests. Placing the GL-DY7027V3B on the ceilings of hotel rooms, lobbies, and conference areas ensures that guests can connect their devices to the hotel's Wi - Fi network without issues. It also supports the hotel's internal wireless systems for staff communication and property management.
Educational Institutions：Schools, colleges, and universities can use the GL-DY7027V3B in classrooms, libraries, and common areas. It enables students and faculty to connect their devices to the campus network, facilitating learning, research, and communication.
Healthcare Facilities：Hospitals and clinics use a variety of wireless devices for patient monitoring, staff communication, and access to medical records. The GL-DY7027V3B can be installed on the ceilings to ensure reliable wireless coverage throughout the facility, contributing to efficient healthcare services.
Q:Is the GL-DY7027V3B compatible with all indoor wireless devices?
A:As long as the wireless devices operate within the 698 - 960MHz or 1710 - 2700MHz frequency bands and support a 50 - ohm impedance, the GL-DY7027V3B should be compatible. However, it's advisable to check the device's specifications for optimal performance.
Q:How does the 360° horizontal beamwidth benefit the antenna's performance?
A:The 360° horizontal beamwidth allows the antenna to cover all directions horizontally. This ensures that wireless devices can receive signals regardless of their position in the room, providing uniform coverage and reducing the likelihood of signal dead zones.
Q:Can the antenna be used in areas with strong sunlight?
A:Yes, the GL-DY7027V3B has an anti - ultraviolet ABS radome, which protects it from UV damage. So, it can be used in indoor areas with some sunlight exposure, such as near windows.
Q:What is the significance of the different gain values in different frequency bands?
A:The 2.5 dBi gain in the 698 - 960MHz band and 3.5 dBi in the 1710 - 2700MHz band are optimized for the specific characteristics of those frequency ranges. The different gain values help to effectively boost the signal strength for devices operating in each band, ensuring better performance and a more stable connection.
Q:How do I install the GL-DY7027V3B antenna?
A:The installation method depends on the input connector type (not specified in the given information). Generally, for ceiling mounting, you should find a suitable location on the ceiling, ensure proper support, and connect the antenna to the relevant wireless system following the provided instructions.
Q:What is the warranty period for the GL-DY7027V3B antenna?
A:The provided information does not mention the warranty period. Please contact our sales team or check the product documentation for specific warranty details.
