LNB Single for RG6 And TV Applications customzied green color
Item | Specification | Item | Specification |
Input Frequency Range | Low Band:10.70~11.70GHz | Gain Flatness | ±0.5d B/26MHz |
High Band:11.70~12.75GHz | Cross POL. Isolation | 25d B(Typ.) | |
Output Frequency Range | Low Band:950~1950MHz | Image Rejection | 40d B(Min.) |
High Band:1100~2150MHz | Output VSWR | 2.0 : 1( Max.) | |
L.O. Frequency | Low Band:9.75GHz | P1dB | 0d Bm (Min.) |
High Band:10.60GHz | DC Current Consumption | 150mA(Typ.) | |
L.O. Frequency Stability | ± 1.0MHz (Max.)@+25C | Low/High Band Switching | Low Band:0Hz |
± 2.0 MHz (Max.)@-30C~+70C | High Band:22KHz±4KHz | ||
L.O. Phase Noise | -60d Bc/Hz@1KHz | POL. Switching Voltage | 10.5~14.0V @Vertical |
-80d Bc/Hz@10KHz | 16.0~20.0V @Horizontal | ||
- 100d Bc/Hz@100KHz | Relative Humidity | 0%~95% | |
Conversion Gain | 60d B(Typ.) | Operating Temperature | -30C~+70C |
Noise Figure | 0.3d B(Typ.) | Connector Type | 75Ω Female Connector |
Product Introduction
Ultra-Low Noise Figure (0.3dB Typ.)
Minimizes signal degradation for crystal-clear HD/4K satellite TV reception, even in weak signal areas.
Dual-Band Frequency Range (10.7–12.75GHz)
Supports both low-band (10.7–11.7GHz) and high-band (11.7–12.75GHz) signals, ideal for global satellite standards like Astra, Hotbird, and DirecTV.
High Conversion Gain (60dB)
Amplifies faint satellite signals effectively, ensuring reliable transmission over long RG6 coaxial cable runs.
Robust Weatherproof Design
Built to withstand extreme temperatures (-30°C to +70°C) and humidity (0–95%), perfect for outdoor installations.
Polarization & Band Switching
Automatically switches between vertical (10.5–14V) and horizontal (16–20V) polarization via DC voltage, simplifying multi-channel setups.
Residential Satellite TV: Delivers stable signals for HD/4K broadcasts in homes.
Rural Internet Connectivity: Compatible with VSAT systems for broadband in remote areas.
Multi-Room TV Systems: Twin/Quad LNBs support multiple receivers for whole-home coverage.
Maritime/Aviation: Provides reliable communication for ships and aircraft using satellite links.
Q:What satellites is this LNB compatible with?
A:Works with Ku-band satellites like Astra 28.2°E, Hotbird 13°E, and DirecTV.
Q:Does it support 4K/UHD broadcasts?
A:Yes, its low noise figure and high gain ensure seamless 4K streaming.
Q:Can I use this LNB with an existing RG6 cable?
A:Absolutely—it’s designed for standard RG6 coaxial connections.
Q:How do I switch between vertical and horizontal polarization?
A:Adjust the receiver’s DC voltage: 13V for vertical, 18V for horizontal.
Q:Is the green casing UV-resistant?
A:Yes, the custom green housing is UV-stable for long-term outdoor durability.
Q:What’s the maximum cable length supported?
A:Up to 50 meters with high-quality RG6/U cables (signal loss <1dB/m).
Q:Does it require a separate power supply?
A:No—it draws power directly from the receiver via coaxial cable.
Q:Can this LNB be used in rainy conditions?
A:Yes, its IP-rated design ensures performance in rain, snow, and humidity.
