GL-DY2458V66
Asialeren
8517710000
| Quantity: | |
|---|---|
| PDF Export | |
Electrical Specifications | |
Frequency Range-MHz | 2400-2500/5150-5850 |
VSWR | ≤1.5 / ≤2.0 |
Gain-dBi | 6 |
Horizontal beam width | 360° |
Verticalbeam width | 40° |
Polarization | Vertical |
Input Impedance-Ω | 50 |
Maximum input power-W | 50 |
Lightning protection | DC Ground |
Mechanical Specifications | |
Input connector type | 6×N-K |
Dimensions-mm | Ф145×185 |
Antenna weight-KGS | 0.9 |
Radome material | ABS/PMMA |
Radome color | White |
Operating temperature | -40°c～60°c |
Rated Wind Velocity-m/s | 60 |
Mounting hardware-mm | ￠35～￠50 |
Dual - band Compatibility：Covering 2400 - 2500MHz and 5150 - 5850MHz frequency ranges, it is suitable for both 2.4G and 5G WLAN/WIFI systems, providing flexibility for different wireless devices and applications.
Multiple Ports：With three 2.4GHz ports and three 5GHz ports, it supports multi - input multi - output (MIMO) technology more effectively. This allows for handling multiple data streams simultaneously, increasing data throughput and improving network performance.
Omni - directional Coverage：The 360° horizontal beamwidth offers all - around signal distribution, ensuring comprehensive wireless coverage in the installation area. Devices in any direction can connect to the network smoothly.
Moderate Gain：Offering a gain of 6 dBi, it provides a reasonable enhancement of the signal strength, which is sufficient for covering a medium - sized area and maintaining stable connections within that range.
Durable Construction：Made of ABS/PMMA radome material, it can withstand different environmental conditions. It has an operating temperature range of - 40°C to 60°C and can endure a rated wind velocity of 60 m/s, making it suitable for both indoor and outdoor use.
Lightning Protection：Equipped with DC ground lightning protection, it safeguards the antenna and connected devices from electrical surges caused by lightning, enhancing the reliability and lifespan of the equipment.
Small - to - Medium - sized Offices：Provides stable and high - speed WIFI coverage for small - to - medium - sized office spaces, enabling employees to connect laptops, smartphones, and other devices for daily work tasks like email communication, file sharing, and web browsing.
Residential Homes：Installed in homes, it ensures strong and consistent WIFI signals throughout the house, supporting activities such as online streaming, gaming, and remote work. The omni - directional coverage helps to eliminate dead zones.
Small Retail Stores：For small retail stores, it offers reliable WIFI for customers to access product information online, make mobile payments, and stay connected while shopping. It can also support the store's internal wireless devices like inventory scanners.
Cafes and Restaurants：Enables customers to enjoy free WIFI while dining or having coffee. The MIMO technology and multiple ports can handle the simultaneous connections of multiple customers' devices, providing a smooth online experience.
Small Event Venues：In small event venues such as meeting rooms or community halls, it can provide WIFI coverage for attendees to use their devices for presentations, communication, and accessing event - related information.
Outdoor Public Spaces with Limited Area：For small outdoor public spaces like parks or gardens with a limited area, it can be installed to offer WIFI access to visitors. Its durable construction allows it to withstand outdoor weather conditions.
Q:What is the maximum input power the GL - DY2458V66 antenna can handle?
A:The maximum input power is 50W.
Q:Can it be installed outdoors?
A:Yes, it is designed to be used outdoors. Its ABS/PMMA radome material and the ability to withstand a rated wind velocity of 60 m/s make it suitable for outdoor installation. However, proper mounting and grounding are recommended.
Q:How does the MIMO technology benefit the user?
A:MIMO technology allows the antenna to send and receive multiple data streams at the same time. This increases the data transfer speed, improves the network's capacity to handle multiple devices, and reduces lag, providing a better overall wireless experience.
Q:Is it compatible with all WIFI routers?
A:It is designed for 2.4G and 5G WLAN/WIFI systems. As long as the router operates within the compatible frequency ranges and supports MIMO technology, it should work. But it's best to check the router's specifications for optimal performance.
Q:What is the significance of the vertical beamwidth of 40°?
A:The 40° vertical beamwidth helps to focus the signal in a specific vertical area. This can be beneficial for optimizing the signal distribution based on the installation height and the target area of coverage, especially in multi - floor buildings or when covering a certain vertical space.
Q:How do I install the antenna?
A:It comes with 6xN - K connectors. You can mount it on a pole with a diameter of 35 - 50 mm using the appropriate mounting hardware. Follow the installation instructions provided for a proper setup.
Q:Does the antenna come with a warranty?
A:Warranty details may vary. Please contact our sales team or check the product documentation for specific warranty information regarding the GL - DY2458V66 antenna.
