S210AM-4P/4PM
Asialeren
8517710000
| Quantity: | |
|---|---|
| PDF Export | |
Item No | S210AM-4P/4PM | |
Panel(Sector Divided) | 4 | |
Aperture Diameter | 210CM | |
C-Band Gain@ 4GHz | 36.8dB | |
Ku-Band Gain@ 12.5GHz | ||
F/D Ratio | 0.385 | |
Focus Length | 80.8CM | |
Material | Aluminium Mesh | |
Finish | Polyester Powder Coating | |
Mounting Type | Pole/Polar Mount | |
Elevation Alignment | 0～90° | |
Azimuth Alignment | 0～360° | |
Operational Winds | Able to receive | 25m/sec |
Able to re-set | 40m/sec | |
Not broken & fly away | 60m/sec | |
Ambient Temperature | -40℃～+60℃ | |
Relative Humidity | 0～100% | |
Product Introduction
Impressive C - Band Gain：The S210AM - 4P/4PM provides an excellent 36.8dB gain in the C - Band at 4GHz. This high gain is a key advantage, allowing the antenna to effectively capture and strengthen weak C - Band signals. Whether for satellite communication, broadcasting, or other C - Band - related applications, it ensures a stable and strong signal connection, delivering reliable performance.
Durable Aluminium Mesh Build：Constructed from aluminium mesh, the antenna is both lightweight and highly durable. Aluminium mesh offers good corrosion resistance, making it suitable for long - term outdoor use. It can endure various weather conditions, including strong winds up to 60m/sec, extreme temperatures, and high humidity, ensuring the antenna's longevity.
Versatile Mounting Options：Featuring a pole/polar mount design with adjustable elevation (0 - 90°) and azimuth (0 - 360°) alignment, the S210AM - 4P/4PM offers great flexibility in installation. Users can easily optimize the antenna's position to achieve the best signal reception, whether it's for covering a specific area or aligning with a particular satellite.
Optimal F/D Ratio and Focal Length：The 0.385 F/D ratio and 80.8CM focal length are carefully designed to focus signals precisely. This optimal combination enhances the antenna's signal - gathering ability, improving its overall performance. It ensures efficient signal collection and transmission, maximizing the utilization of satellite signals.
Wide - ranging Environmental Adaptability：Operating within a temperature range of - 40 ℃ to +60 ℃ and a relative humidity of 0 - 100%, the antenna can function in diverse environments. This wide tolerance makes it suitable for use in different climates, from freezing cold regions to humid tropical areas, ensuring continuous operation without performance degradation.
Application scenarios
Satellite Broadcasting: Ideal for TV/radio stations requiring stable, high-gain signal transmission.
Defense & Tactical Systems: Deployed in remote or hostile environments for secure communication.
Maritime & Offshore Operations: Corrosion-proof design ensures reliability on ships and oil rigs.
Meteorology & Disaster Monitoring: Built to endure extreme weather for critical data transmission.
Rural & Remote Connectivity: Provides affordable satellite internet solutions to underserved regions.
Q:What is the maximum wind resistance?
A:The antenna survives 60m/sec winds without damage and resets after 40m/sec gusts.
Q:Can it function in freezing temperatures?
A:Yes, it operates reliably at -40℃, making it suitable for Arctic or high-altitude deployments.
Q:Does it support Ku-band frequencies?
A:Primarily optimized for C-band (4GHz); contact for Ku-band compatibility details.
Q:What mounting options are available?
A:Supports pole or polar mount installations for versatile positioning.
Q:How durable is the aluminum mesh?
A:Resists rust and corrosion even in 100% humidity or salt-heavy maritime environments.
Q:How does the 4-sector design improve performance?
A:It distributes signals efficiently, minimizing dead zones and interference.
